KYMCO Downtown 200i Service Manual

13. FUEL INJECTION SYSTEM
13-20
DOWNTOWN 200i
FUEL INJECTOR
INSPECTION
Disconnect the fuel injector connector.
Measure the resistance between 2 pins of the
fuel injector connector.
Standard: 11.7±0.6 Ω (at 20°C/68°F)
REMOVAL
Disconnect the connector from the fuel
injector.
Remove the bolt of the fuel injector.
Take out of the fuel pipe and fuel injector
from the Inlet pipe.
Remove the fuel injector from the fuel pipe.
Connecto
r
Bolt
Ensure the fuel pipe without any
pressure, then remove the fuel injector.
STEP 1: Disconnect the fuel pump relay
or fuel pump connector.
STEP 2: Turn the key to the ON
position. Starting the engine till the
engine stop working.
＊
O-rin
g
Fuel Injector

KYMCO Downtown 200i Specifications

General

Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic Fork
Starting System	Electric
Rear Tire	150/70-13
Transmission	CVT
Rear Suspension	Dual shocks
Front Brake	Disc
Rear Brake	Disc
Front Tire	120/14
Wheelbase	1, 550 mm
