KYMCO Downtown 200i Service Manual

14.HANDLEBAR/FRONT WHEEL/FRONTBRAKE/
FRONT SHOCK ABSORBER/STEERING STEM
14-14
DOWNTOWN 200i
FRONT SHOCK ABSORBER
REMOVAL
Remove the front cover and front fender.
Remove the front brake caliper
Remove the front wheel
Remove the speed wheel sensor bolt and then
remove the brake hose guide from right front
shock absorber.
Remove the speedometer cable guide from
left front shock absorber.
Remove two mounting bolts and then remove
the right/left front shock absorber.
INSTALLATION
Installation is in the reverse order of removal.
Specified Oil: SS#8
Oil Capacity: 185 cc
INSPECTION
Inspect the following items and replace if
necessary.
•Front shock absorber tube bending, dam
age
or wear
•W
eak front shock absorber spring
•Dam
per and damper rod bending
•Oil seal damage or wear
Tighten the shock absorber mounting
bolt to the specified torque.
Torque: 2.7 kgf-m (27 N-m, 19.5 lbf-ft)
＊
Speed Wheel Sensor
Mounting Bolts
Left
Right

KYMCO Downtown 200i Specifications

General

Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic Fork
Starting System	Electric
Rear Tire	150/70-13
Transmission	CVT
Rear Suspension	Dual shocks
Front Brake	Disc
Rear Brake	Disc
Front Tire	120/14
Wheelbase	1, 550 mm
