3. INSPECTION/ADJUSTMENT
3-5
DOWNTOWN 200i
The spring will come out when the filter cap is
removed.
Let the engine oil drain out.
Check that the O-ring is in good condition.
Install a new oil filter.
RESERVE TANK
COOLANT LEVEL INSPECTION
The reserve tank is under left floorboard .Check the
coolant level through the inspection window(1) at the
left side skirt white the engine is at the normal
operating temperature , with the scooter In an upright
position.
If the coolant level is below the LOWER level
m
ark(3), remove the left floor mat ,remove the lid
screw(4), the reserve tank lid(5), and then the reserve
tank cap(6) to add coolant mixture until it reaches the
upper level mark .
Spring
Make sure the rubber seal on the oil filter
facing the left crankcase.
＊
Add coolant to the reserve tank only. Do not
attempt to add coolant by removing the
radiator cap. Coolant in the radiator is under
pressure and is very hot and can cause
serious burns.
＊
