15. REAR WHEEL/AXLE/SUSPENSION/
DRIVING MECHANISM
15-14
MXU 300/250
Tighten the two rear axle nuts (inner and
outer).
Special tool: Nut wrench F010
Torque: 12 kgf-m (120 Nm, 86 lbf-ft)
Adjust drive chain slack. (Refer to the
“DRIVE CHAIN SLACK ADJUSTMENT”
section in the CHAPTER 3.)
Drive chain slack: 30 ~ 40mm
Note that the rear axle nuts are left
threaded.
＊
