5. FUEL SYSTEM
5-7
MXU 300/250
THROTTLE VALVE
DISASSEMBLY
Remove the fuel tank. (Refer to “FUEL
TANK” section in the chapter 5)
Remove the carburetor cap.
Pull out the throttle valve.
Compress the spring to disconnect the
throttle cable by hand.
Carburetor Cap
Throttle Valve
Throttle Cable
