KYMCO PEOPLE S 125 Service Manual

8. CYLINDER/PISTON
8-4
PEOPLE S 4T
CYLINDER REMOVAL
Turn the cam chain tension screw clockwise
to tighten it.
Remove the two bolts on the cam chain
tension.
Remove the cylinder head. (
Ö
7-7)
Remove the cam chain guide.
Remove the cylinder base bolts.
Remove the cylinder.
Remove the cylinder gasket and dowel pins.
Clean any gasket remnant from the cylinder
surface.
PISTON REMOVAL
Remove the piston pin clip.
Press the piston pin out of the piston and
remove the piston.
Dowel Pins
Cylinde
r
Piston
Piston Rings
Bolt
Place a clean shop towel in the
crankcase to keep the piston pin clip
from falling into the crankcase.
＊

KYMCO PEOPLE S 125 Specifications

General

Displacement	124.6 cc
Front Suspension	Telescopic Fork
Cooling System	Air Cooled
Max Torque	10.4 Nm @ 6500 rpm
Transmission	CVT
Front Brake	Disc
