KYMCO Quannon 125 User Manual

9. EASY MAINTENANCE
(1) AIR CLEANER INSPECTION AND AIR CLEANER
CLEANING & REPLACEMENT
Take out the air cleaner cover and visually check if it is
dirty or clogged.
1.Remove the screws attaching the air cleaner cover and
emove the air cleaner cover.
2.Remove the air cleaner element.
3.The installation sequence is the reverse of removal.

r
38
1.Remove the rear seat.(see P.12)
2.Remove the bolt on the front seat.
3.Remove the front seat.
Bolt

KYMCO Quannon 125 Specifications

General

Displacement	124.1 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	5-speed
Front Suspension	Telescopic fork
Front Brake	Disc
Seat Height	780 mm
Rear Brake	Disc
Rear Suspension	Mono shock
