Kyocera ECOSYS M3040idn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-24
1020 PF lift motor 1 error
(paper feeder)
After cassette 2 is inserted,
PF lift sensor 1 does not turn
on. This error is detected four
times successively.
Bottom plate ele-
vation mechanism
in the cassette
Check to see if the bottom plate can move
smoothly and repair it if any problem is
found.
Connector cable or
poor contact in the
connector
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF lift motor 1 and PF main PWB (YC7)
Drive transmission
system of the PF
lift motor
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
PF lift motor Replace the PF lift motor 1.
PF main PWB Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
1030 PF lift motor 2 error
(paper feeder)
After cassette 3 is inserted,
PF lift sensor 2 does not turn
on. This error is detected four
times successively.
Dottom plate ele-
vation mechanism
in the cassette
Check to see if the bottom plate can move
smoothly and repair it if any problem is
found.
Connector cable or
poor contact in the
connector
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF lift motor 2 and PF main PWB (YC7)
Drive transmission
system of the PF
lift motor
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
PF lift motor Replace the PF lift motor 2.
PF main PWB Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
1040 PF lift motor 3 error
(paper feeder)
After cassette 4 is inserted,
PF lift sensor 3 does not turn
on. This error is detected four
times successively.
Bottom plate ele-
vation mechanism
in the cassette
Check to see if the bottom plate can move
smoothly and repair it if any problem is
found.
Connector cable or
poor contact in the
connector
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF lift motor 3 and PF main PWB (YC7)
Drive transmission
system of the PF
lift motor
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
PF lift motor Replace the PF lift motor 3.
PF main PWB Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Code Contents Related parts
Check procedures/
corrective measures

Kyocera ECOSYS M3040idn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	9 s
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (color)	30 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor family	PowerPC
Card reader integrated	No
Maximum internal memory	2048 MB
Sound power level (standby)	27.8 dB
Sound pressure level (copying)	51.5 dB
Sound pressure level (quiet mode)	47.9 dB
Paper input type	Paper tray
Total input capacity	600 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	61 W
Power consumption (PowerSave)	2.4 W
Power consumption (average operating)	684 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TUV/GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
