Kyocera ECOSYS P7240cdn - Connectors;Interior

2-3
Installing and Setting up the Machine > Part Names
Connectors/Interior
1 USB Port
2 USB Interface Connector
3 Network Interface Connector
4 Option Interface
5 Feed Cover
6 Size Dial
7 Paper Length Guide
8 Paper Width Guides
9 Multi Purpose Tray
10 Paper Width Guides
11 Fuser Cover
