Make sure the battery box or battery pack is removed
before replacing the colored grip and pad.
7
●
Steering Wheel Adjustment
●
Throttle Trigger Adjustment
●
Wheel Cap Remove
●
Throttle Trigger Position Adjustment
●
Colored Grip and Pad Replacement
● ET Keys (1-3) and BT Button (1)
《How to change》
Adjust the tension of the steering wheel spring.
Insert a 1.5mm hex wrench referring to the image below.
Rotate clockwise to increase tension and counterclockwise to
decrease it.
[How to Adjust]
Hex Wrench
Excessive counterclockwise rotation will result in the wheel being
unable to return to neutral position. In this case, rotate clockwise
until the wheel returns to neutral.
Temperature and aging, because it may become loose by the
strong impact or the like, it is recommended that you adhere to
such cases. In the case where there is a thing that would loose
still, please contact the user consultation room.
Insert Wheel Cap Remover to the wheel cap spoke.
Pull up Wheel cap remover with Wheel Cap.
Since the screw will appear If you remove
the handle cap, it will be able to remove the
steering wheel by removing the screw.
Adjust the position and angle of the brake trigger to your
preferences.
Loosen the hex screws on the throttle trigger with a 1.5mm
hex wrench.
Freely adjust the brake trigger position.
Tighten the hex screws to secure.
[How to Adjust]
Throttle Trigger
Brake Trigger
Hex Screws
Ball Joint
The position of the throttle trigger may be adjusted to match the
user's hands.
Loosen two screws on the rear side of the transmitter.
Slide the Throttle Trigger Position Adjuster as desired.
Tighten the loosened screws to secure.
[How to Adjust]
Screws
Throttle Trigger
Position Adjuster
To Next Page
