L.R. Baggs Venue D.I. User Manual

B
CD
E
F
G
A
H
REAR AND SIDE PANELS
A. Input
The 1/4” input, located on the upper right side of the unit, is an unbalanced (mono) all
discrete input with a 10 megaohm impedance. It can be used with almost any passive
or active pickup or pickup system. Plugging into the input will turn the system on,
therefore unplugging will turn the system o . Before unplugging from the Venue D.I. be
sure to mute the sound system or ampli er, or a loud pop will occur.
B. EFX Send
Connect a standard 1/4” mono cable from this jack to the input of an e ects pedal or
rack device.
C. EFX Return
Connect the return of the output of an e ects pedal or rack device to interrupt the signal
and complete the series e ect loop.
