SCADA INTERFACE INSTRUCTIONS - OPTION 21Q - FOR A36D/TPSD SYSTEMS/341S
Page 8 of 10
01 - Coils
Address
Name/Description
00021
Test Low Voltage Alarm Contacts (BEGIN TEST=1, END TEST=0).
00022
Test Positive Ground Contacts (BEGIN TEST=1, END TEST=0). TPSD ONLY.
00023
Test AC Alarm Contacts (BEGIN TEST=1, END TEST=0).
00024
Test Summary Alarm Contacts (BEGIN TEST=1, END TEST=0).
00025
Test Low Current Alarm Contacts (BEGIN TEST=1, END TEST=0).
00026
Test Open DC Protection Alarm Contacts (BEGIN TEST=1, END TEST=0). A36D ONLY.
02 - Discrete Inputs
Address
Name/Description
10000
AC Alarm Indicator (FAILURE=1)
10001
High Voltage Alarm Indicator (FAILURE=1)
10002
High Voltage Shutdown Alarm Indicator (FAILURE=1)
10003
Low Current Alarm Indicator (FAILURE=1)
10004
Open DC Protection Alarm Indicator (FAILURE=1) A36D ONLY.
For TPSD this point will always read 0.
10005
Positive Ground Alarm Indicator (FAILURE=1). TPSD ONLY.
For A36D this point will always read 0.
10006
Negative Ground Alarm Indicator (FAILURE=1). TPSD ONLY.
For A36D this point will always read 0.
10007
Summary Alarm Indicator (FAILURE=1)
10008
End of Discharge Alarm Indicator (FAILURE=1).
10009
Overload Alarm Indicator (FAILURE=1)
10010
Over Temperature Alarm Enable (ENABLED=1)
10011
Over Temperature Alarm Status (FAILURE=1)
10012
Charger in Settings Menu (Set to 1 when charger is manually put into the settings menu
through the front panel) Remote setting changes are disabled when this is set to 1 until
the local operator exits the Settings Menu.
10013
SCADA Read Only Mode (ENABLED=1). Setting changes are not allowed when the
charger is in the settings menu or when the SCADA Read Only Mode has been selected.
10014
Negative Ground Alarm Relay Contacts (CLOSED=1, OPEN=0). TPSD ONLY.
10015
High Voltage Alarm Relay Contacts (CLOSED=1, OPEN=0).
10016
Low Voltage Alarm Relay Contacts (CLOSED=1, OPEN=0).
10017
Positive Ground Alarm Relay Contacts (CLOSED=1, OPEN=0). TPSD ONLY.
10018
AC Fail Alarm Relay Contacts (CLOSED=1, OPEN=0).
10019
Summary Alarm Relay Contacts (CLOSED=1, OPEN=0).
10020
Low Current Alarm Relay Contacts (CLOSED=1, OPEN=0).
10021
Open DC Protection Alarm Relay Contacts (CLOSED=1, OPEN=0).
