SCADA INTERFACE INSTRUCTIONS - OPTION 21Q - FOR A36D/TPSD SYSTEMS/341S
Page 9 of 10
Description, Units, Valid Settings/Range
Equalize Timer Mode (0,1 2,3,4)
Equalize Timer Setting (0 to 144)
Low Voltage Alarm Threshold, Volts, (0 to MAXAV)
High Voltage Alarm Threshold, Volts, (0 to MAXAV)
High Voltage Shutdown Alarm Threshold, Volts, (0 to MAXAV)
Low DC Current Alarm Threshold, Amps, (0 to MAXAI)
Low DC Current Alarm Recovery Threshold, Amps (Low DC
Current Alarm Threshold to MAXAI)
Low Voltage Alarm Recovery Threshold, Percent (0 to 20)
Low Voltage Alarm Delay, Seconds, (1 to 300)
Equalize Timer Mode 4 (Auto Equalize on LV Alarm Recovery)
Delay, Seconds (1 to 300)
High Voltage Alarm Delay, Seconds, (1 to 300)
High Voltage Alarm Recovery Threshold, Percent (0 to 20)
High Voltage Shutdown Alarm Delay, Seconds, (1 to 300)
Low Current Alarm Delay, Seconds, (1 to 300)
End of Discharge Alarm Threshold, Volts, (0 to MAXAV)
End of Discharge Alarm Recovery Threshold, Percent (0 to 20)
Overload Alarm Threshold, Amps, (0 to MAXAI)
Overload Alarm Recovery Threshold, Percent (0 to 20)
AC Alarm Delay, Seconds, (1 to 300)
Ground Detection Alarm Delay, Seconds, (1-300) TPSD
ONLY. For A36D this point will always read 0 and writes to are
prohibited.
End of Discharge Alarm Delay, Seconds (1-300)
Overload Alarm Delay, Seconds (1-300)
Heartbeat
This register increases once per second and may be used to
determine if communications are still occurring.
Board Number. Will read 205 for 205T card.
Software Version, Version of software on 205T card.
Equalize Cycle Time Hours Remaining, Hours, Minutes
Note: The last two digits are the minutes.
Auto Equalize Timer, Days
Auto Equalize Timer, Hours, Minutes
Note: The last two digits are the minutes.
Low DC Current Alarm Low Limit, Amps. Setting the Low DC
Current Alarm below this will result in disabling the Low DC
Current Alarm Status Indicator.
