La Spaziale Compact S9 - 1 General Description of the Machine

espresso coffee machines
3
8
9
-
LSI 089 - Rev. 00 - Ed. 04/2015
1 GENERAL DESCRIPTION OF THE MACHINE
LEGEND
1. Top cup grid
2. Steam delivery knob
3. Hot water delivery knob
4. Touchpad
5. LED light display
6. Control panel
7. 2-cup filter holder
8. Right steam wand
9. Drip tray grid
10. Water drip tray
11. Boiler pressure gauge
12. Main on/off switch
13. Adjustable foot
14. Water mains gauge
15. Left steam wand
16. Water level glass
17. Hot water output
18. One-cup filter holder
19. Filling valve
Fig. 1
S8
4 4
3
1 2
2
5 6
00
00
00
00
00
00
00
16
17
19
15
14
13
12
11
10
9
8
7
18
