La Spaziale Compact S9 - Page 7

espresso coffee machines
5
8
9
-
LSI 089 - Rev. 00 - Ed. 04/2015
LEGEND
1. Top cup grid
2. Steam delivery knob
3. Hot water delivery knob
4. Touchpad
5. LED light display
6. Control panel
7. 2-cup filter holder
9. Drip tray grid
10. Water drip tray
11. Boiler pressure gauge
12. Main on/off switch
13. Adjustable foot
14. Water mains gauge
15. Left steam wand
16. Water level glass
17. Hot water output
18. One-cup filter holder
19. Filling valve
20. Automatic steam delivery button for milk
foaming - M.A.T.- (optional)
21. Steam wand with temperature sensor -
M.A.T. - (optional)
23. Air adjustment for milk foaming - M.A.T.
- (optional)
Fig. 3
S8 MAT
4 4
3
1 2
20
5 6
00
00
00
00
00
16
17
19
15
14
13
12
11
10
9
21
23
7
18
