Specifications
GENERAL FEATURES
•
160-6-meter ham bands;
•
General ‘receive’ coverage 0.5 - 56.0 MHz;
•
All modes: SSB, CW, DIG, AM, FM;
•
High-performance 32-bit floating-point DSP;
•
Current drain as low as 100 mA in ‘receive’ mode (backlight on, preamp off, no signal);
•
External power supply DC 9-15V, 1 to 3A typical in transmit;
•
High-contrast LCD with 256*128 px;
•
High-performance real-time pan-adapter (48 kHz wide);
•
On-line rmware updates;
•
Rear folding kickstands for viewing angle and transportation;
•
Ultra-compact size (H*W*D): 90 mm (3.5") * 207 mm (8.1") * 21 mm (0.8");
•
Weight: 0.55 Kg (19.4 oz).
RECEIVER *
•
Sensitivity (MDS) -136 dBm (typ. with preamp on);
•
Quadrature down-sampling mixer compatible with PC-based SDR (software dened
radio) applications;
•
Receiver I / Q outputs for PC soundcard;
•
Switchable low-noise preamp and attenuator;
•
3-band receive audio equalizer;
•
4 adjustable digital lters;
•
Automatic notch ltering;
•
Adjustable noise reduction and noise blanking;
•
Audio Output ext. speaker, 3W typ.
TRANSMITTER *
•
Adjustable output, 1 to 10W HF (7W 6m);
•
Rugged, SWR and temperature-protected nal amplier stage;
•
Carrier Suppression > 50 dB typ.;
•
Harmonic / Spurious Outputs > 50 dB below carrier;
•
CW Sidetone/Transmit offset 400-1200 Hz, adjustable;
•
Speaker-microphone with PTT;
•
3-band microphone audio equalizer;
•
2 adjustable digital lters;
•
DSP RF speech processing for excellent 'punch'.
* Specications apply only within ham bands except as noted. All measurements taken with 13.8 VDC supply.
