Chapter 4: Lyo-Works Operating System
Product Service 816-333-8811 or 1-800-522-7658
Touch Screen Operation
Home Screen
After initial power up, the Home screen will be displayed. Most of the general
operation and system monitoring can be done from the Home screen.
Main Menu Icons
Menu icons are displayed across the top of the screen. Their descriptions from left
to right are as follows:
1. Home
2. Programs
3. Data Logging
4. Settings
5. Sensors
6. (Empty)
7. End Point Detection
8. Help
Moving between Menu Screens
You can move between menu screens by either touching the menu icons or
swiping across the screen from left to right or right to left.
The Following system parameters are displayed in the center portion of the screen:
Function Indicator Bar
A thin blue indicator bar will appear under the icon of the menu screen that is
currently being displayed. The same type of indicator bar will appear above the
operation buttons to signify if each function is ON or OFF.
