Appendix B: Dimensions
The following figures provide product dimensions. All dimensions shown in inches
(centimeters).
Undercounter Exterior Dimensions
Freestanding Exterior Dimensions
27.7
(70.4)
50.2
(127.5)
24.1
(61.2)
32.1 MIN (81.5)
36.0 MAX (91.4)
27.8
(70.6)
50.2
(127.5)
24.3
(61.7)
32.2 (81.8) MIN
36.1 MAX (91.7)
Figure B-1
Figure B-2
