LABEL-AIRE Write-up 3138NV-DAT - SWING TAMP ADJUSTMENT

41


SWING TAMP ADJUSTMENT
Thetamppressureandflowcontrolsweresetatthefactory.Usethefollowinginstructionsto
checkthetampfunctionandtomakeadjustmentsifnecessary.
Exercisecautionwhencyclingthemachine.Keephandsawayfromthetamp.
1.Settheswingtampairpressureregulatorto60P.S.I.(40bar)
2.Disablethetamp.
3.FromtheAdvancedMenuselectswingtampextendtime=xxx
Usethe[up]and[down]buttontosetswingtampextendtime
=500.
4.FromtheServiceMenuselecttampblow=Yes.
5.Pressthe[FEED]buttontocycletheswingtampseveraltimeandobservethetampaction.
Theswingtampshouldmovequicklyandsmoothlywithoutslammingtoastopateitherendof
travel
Ifthetampfunctionsproperly,leavethe[tamp]inDisablemodeandpressthe[enter]button.
Ifthetampdoesnotmovequicklyandsmoothly,orifitslamstoastopateitherendof
travel,continuewithstep6.
6.Locatetheswingtampflowcontrolslocatedonthetampsupportassembly.
7.loosentheswingtampflowcontrollocknutswitha3/8inchopenendwrench.




