Label EVOLUS-90T User Manual

1) INDICATIVE SYSTEM DESCRIPTION
2) EVOLUS - EVOLUS-T OPERATOR TECHNICAL DATA
POWER SUPPLY
POWER
FREQUENCY OF USE
WORKING TEMPERATURE
PROTECTION DEGREE
EVOLUS TRANSOM DIMENSIONS (H x D)
POWER SUPPLY OF EXTERNAL ACCESSORIES
230Vac +/-10%, 50-60Hz
80W
continuous
-15°C +50°C
IP22
13 Vdc
OPERATOR MODEL
4
PAUSE TIME Max. 20 sec.
AUTOMATISM
POWER SUPPLY
OUTER
SIDE
INNER
SIDE
1
2
3
4
5
6
Internal movement and presence sensor for door opening and safety during closing
Emergency opening button
Digital programmer
External movement and presence sensor for door opening and safety during closing
Opening safety sensor
Key button
7
EVOLUS operator
7
EVOLUS-T TRANSOM DIMENSIONS (H x D)
EVOLUS-90T
EVOLUS-T T200T EVOLUS-150T EVOLUS-T T200T
130W
120 x150 mm
120 x210 mm
