DB15 Pinouts
1
Vs
9
CIO0
2
CIO1
10
CIO2
3
CIO3
11
GND
4
EIO0
12
EIO1
5
EIO2
13
EIO3
6
EIO4
14
EIO5
7
EIO6
15
EIO7
8
GND
Table 2.13-1. DB15 Connector Pinouts
2.13.1 - CB15 Terminal Board
The CB15 terminal board connects to the LabJack UE9’s DB15 connector. It provides convenient screw terminal access to the 12
digital I/O available on the DB15 connector. The CB15 is designed to connect directly to the LabJack, or can connect via a
standard 15-line 1:1 male-female DB15 cable.
2.13.2 - RB12 Relay Board
The RB12 relay board provides a convenient interface for the UE9 to industry standard digital I/O modules, allowing electricians,
engineers, and other qualified individuals, to interface a LabJack with high voltages/currents. The RB12 relay board connects to
the DB15 connector on the LabJack, using the 12 EIO/CIO lines to control up to 12 I/O modules. Output or input types of digital I/O
modules can be used. The RB12 is designed to accept G4 series digital I/O modules from Opto22, and compatible modules from
other manufacturers such as the G5 series from Grayhill. Output modules are available with voltage ratings up to 200 VDC or 280
VAC, and current ratings up to 3.5 amps.
2.14 - OEM Connector Options
As of this writing, the UE9 is only produced in the normal form factor with screw-terminals and DB connectors, but the PCB does
have alternate holes available for 0.1” pin-header installation.
Connectors J2 and J3 provide pin-header alternatives to the DB15 and DB37 connectors:
J2
1
GND
2
Vs
3
CIO0
4
CIO1
5
CIO2
6
CIO3
7
GND
8
EIO0
9
EIO1
10
EIO2
11
EIO3
12
EIO4
13
EIO5
14
EIO6
15
EIO7
16
GND
Table 2.14-1. J2 OEM Pin-Headers
J3
1
GND
2
GND
3
PIN20
4
PIN2
5
FIO7
6
FIO6
7
FIO5
8
FIO4
9
FIO3
10
FIO2
11
FIO1
12
FIO0
13
MIO0
14
MIO1
15
MIO2
16
GND
17
Vs
18
Vm-
19
Vm+
20
GND
21
DAC1
22
DAC0
23
GND
24
AIN13
25
AIN12
26
AIN11
27
AIN10
28
AIN9
29
AIN8
30
AIN7
31
AIN6
32
AIN5
33
AIN4
24
AIN3
35
AIN2
36
AIN1
37
AIN0
38
GND
39
GND
40
GND
Table 2.14-1. J3 OEM Pin-Headers
3 - Operation
The following sections discuss command/response mode and stream mode.
Command/response mode is where communication is initiated by a command from the host which is followed by a response from
the LabJack. Command/response is generally used at 1000 scans/second or slower and is generally simpler than stream
25
