Write: Set to non-zero if new values should be updated. Pass 0×00 if only reading. A value of non-zero will only work if the
command is sent via USB.
IP #0: First IP address allowed to connect. A value of 0xFFFFFFFF disables feature.
IP #1: Second IP address allowed to connect.
IP #2: Third IP address allowed to connect.
IP #3: Fourth IP address allowed to connect.
IP #4: Fifth IP address allowed to connect.
5.3 - Control Functions
These are functions that are handled by the Control processor, and thus the packet destination bit is 1 for remote. Most functions
can be transferred by USB, Ethernet TCP, or Ethernet UDP. The exception is stream commands which are not supported over
UDP.
5.3.1 - BadChecksum
5.3.2 - ControlConfig
Configures various parameters associated with the Control processor. Although this function appears to have many of the same
digital I/O and DAC parameters as other functions, most parameters in this case are affecting the power-up values, not the current
values.
If WriteMask is nonzero, some or all default values are written to flash. The Control flash has a rated endurance of at least 20000
writes, which is plenty for reasonable operation, but if this function is called in a high-speed loop with a nonzero WriteMask, the
flash could be damaged.
There is a hardware method to restore parameters to the default values described below (in parentheses). Power up the UE9 with
a short from FIO2<=>SCL, then remove the jumper and power cycle the device again. This also returns Comm (Section 5.2.1) and
Watchdog (Section 5.3.13) settings to factory defaults.
Note: If the stream is running, you cannot update any of the values (WriteMask must equal 0).
