Dir/BipGain/DACL: For a digital bit write, this is 0 for input, and 1 for output. For a digital port write, this is multiple bits
specifying input or output for each line. Ignored for digital reads. For an analog input this is the BipGain parameter (see
Feedback). For an analog output this is the low byte of the binary output value.
State/Resolution/DACH: For a digital bit write, this is the output state. For a digital port write, this is multiple bits specifying
the output state for each line. Ignored for digital reads. For an analog input this is the Resolution parameter (12-18). For an
analog output this is the most significant 4 bits of the binary output value, and the upper 4 bits are ignored as the output is
always updated and IOType=5 causes both DACs to be enabled.
SettlingTime: Only applies to analog inputs (see Feedback).
Dir/AINL: For a digital bit read, this reads 0 for input, and 1 for output. For a digital port read, this is multiple bits returning
input or output for each line. For digital writes this is just an echo. For an analog input this is the lowest 8 bits of the 24-bit
conversion value (generally ignored on the UE9).
State/AINM: For a digital bit read, this is a read of the input state. For a digital port read, this is multiple bits returning a read
of the input state for each line. For digital writes this is just an echo. For an analog input this is the middle 8 bits of the 24-bit
conversion value, or more typically considered the lowest 8 bits of the 16-bit conversion value.
AINH: For an analog input this is the high 8 bits of the 24-bit conversion value, or more typically considered the high 8 bits of
the 16-bit conversion value. Binary readings are always unsigned integers.
5.3.5 - TimerCounter
Enables, configures, and reads the counters and timers.
