LabJack UE9 - Page 75

Command:
Byte
0
Checksum8
1
0xF8
2
0x12
3
0x12
4
Checksum16 (LSB)
5
Checksum16 (MSB)
6
Number of Points
7
Reserved
8
Reserved
9
StreamDAC Config
Bit 7: 1=DAC1, 0=DAC0
Bits [0:2]: Block number (0-7)
10
DAC Value (0 + 16 * BlockNum) L
11
DAC Value (0 + 16 * BlockNum) H
...
40
DAC Value (15 + 16 * BlockNum) L
41
DAC Value (15 + 16 * BlockNum) H
Response:
Byte
0
Checksum8
1
0xF8
2
0x01
3
0x12
4
Checksum16 (LSB)
5
Checksum16 (MSB)
6
Errorcode
7
0x00
To enable StreamDAC set the number of points to a value greater than zero, to disable set the value to zero.
When loading multiple blocks of points, byte 6 (Number of Points) should be set to the total number of points the DAC should cycle
through.
Up to 128 points can be loaded, 16 at a time. Use bits [0:2] in byte 9 to select which block of 16 is being loaded.
5.3.23 - SetDefaults (SetToFactoryDefaults)
Executing this function causes the current or last used values (or the factory defaults) to be stored in flash as the power-up defaults.
The UE9 flash has a rated endurance of at least 20000 writes, which is plenty for reasonable operation, but if this function is called
in a high-speed loop the flash could eventually be damaged.
Note: Do not call this function while streaming.
Command:
Byte
0
Checksum8
1
0xF8
2
0x01
3
0x0E
4
Checksum16 (LSB)
5
Checksum16 (MSB)
6
0xBA (0x82)
7
0x26 (0xC7)
Response:
Byte
0
Checksum8
1
0xF8
2
0x01
3
0x0E
4
Checksum16 (LSB)
5
Checksum16 (MSB)
6
Errorcode
7
0x00
5.3.24 - ReadDefaults (ReadCurrent)
