22 | MSD Legend Series Operation & Maintenance Manual
80-HOUR INSPECTION CHECKLIST
Build-up, hard-surfacing & Blade Rotation
________ Build-up jaws and hard surface, if necessary (See “Jaw Build Up & Hardsurfacing” on page 38).
________ Check wear plates and bars. Replace if necessary (see “Replace Wear Plates & Bars” on page 41).
________ Inspect slide screw (see “Slide Screw Adjustment” on page 41).
________ Rotate blades (see “Blade Rotation” on page 31). Record which rotation you performed.
________ First Rotation ________ Second Rotation ________ Third Rotation ________ Fourth Rotation
________ Inspect the cylinder gap (see “Check the Cylinder Gap” on page 42).
Inspected By: _______________________________________________ Date:_____________________
1500-HOUR INSPECTION CHECKLIST
________ Replace rotation bolts (see “Inspect / Torque Bolts” on page 25 for proper bolt size and class).
Inspected By: _______________________________________________ Date:_____________________
2,000- HOUR INSPECTION CHECKLIST
Replace Select Seals
________ Replace cylinder seals.
________ Replace swivel manifold seals, if equipped.
Inspected By: _______________________________________________ Date:_____________________
