TABLE A
Par.N Identification Minimum and Maximum Limits Factory Setting Current Value
1 pass code 0 ... 255 0 ____
2 stand-by YES / NO YES ____
3 (language) Italiano... English
Español
4 LCD contrast 00 ... 100 50
LEVEL #1, accessible with pass code 24
5 main SET min.range ... +3.00 b
... max.range
6 alternative SET min.range ... +3.50 b
... max.range
7 dead zone 0.0 ... 2.00 bar 0.20 b
8 HP. alarm delay 0 ... 300 minutes 5 min
9 compr.cut-in dly 0 ... 240 seconds 10 sec
10 compr.stop dly 0 ... 240 seconds 10 sec
11 min.compr.stop 0 ... 20 minutes 3 min
12 max.compr.run 0 ... 120 minutes 60 min
13 stage cut-in dly 0 ... 240 seconds 5 sec
14 stage stop dly 0 ... 240 seconds 5 sec
15 warming-up 0 ... 120 minutes 0 min
16 scaling limit. 0 ... 8 0
17 peripheral No. 1 ... 255 1
LEVEL #2, accessible with pass code 69
18 No. compressors 1 ... 8(?) 4
19 No. stage/compr. 1 ... 8(?) 1
20 compr.rotation YES / NO YES
21 refrigerant R22, R134A,
R404A-507 R134A
22 probe offset -1.00 ... +1.00 0.00 bar
23 min.probe input 0 ... 5 mA 4 mA
24 min.range -1.00 ... +1.00 bar -0.7 b
25 max.range +1.00 ... +9.00 bar +8.00 b
26 altern.SET input YES / NO NO
27 out 1 diagn. YES / NO NO
LEVEL #2, (continues)
28 out 2 diagn. YES / NO NO
29 out 3 diagn. YES / NO NO
30 out 4 diagn. YES / NO NO
31 out 5 diagn. YES / NO NO
32 out 6 diagn. YES / NO NO
33 out 7 diagn. YES / NO NO
34 out 8 diagn. YES / NO NO
35 HP press.input YES / NO NO
36 LP press.input YES / NO NO
37 lqd.level input YES / NO NO
38 auxil. input YES / NO NO
39 lqd.level delay 0 ... 120 minutes 10 min
LEVEL #3, accessible with pass code 104
40 next mainten. 500 ... 30'000 hours 1000 hrs
41 out 1 run time 0 ... 50 hours 0
42 out 2 run time 0 ... 50 hours 0
