INSTRUCTIONS FOR INSTALLATION AND USE.
SSD90BXX(X-C): STANDARD SETUP
P ARAMETER R ANGE
F ACTORY SETTING P ARAMETER R ANGE F ACTORY SETTING
SPL -40.. SPH [°] -25 ACT 0.. 250 [°] 70
SPH SPL.. +250 [°] -18 CSD 0.. 30 [min] 00
SP SPL.. SPH [°] -20 CFT -40.. +250 [°] 00
HYS -30.. 0.. +30 [°] 03 CRT 0.. 30 [min] 03
DFR 0.. 24 04 CDC 0.. 10 07
DLI 0.. +70 [°] 10 OFF YES/NO YES
DTO 1.. 120 [min] 20 DS YES/NO NO
DTY OFF/ELE/GAS ELE LDO YES/NO YES
DRN 0.. 30 [min] 03 T2 YES/NO YES
DDY 0.. 60 [min] 15 T3 Don’t modify NO
FPC 0 ... 5 00 SCL °C/°F °C
FDD -40.. +70 [°] 00 OS1 -15.. +15 [°] 00
ATL -25.. 0 [°] -03 OS2 -15.. +15 [°] 00
ATH 0.. +25 [°] 05 OS3 -15.. +15 [°] 00
ATD 0.. 120 [min] 30 SIM 0.. 100 03
ADO 0.. 120 [min] 05 ADR 0.. 255 01
ACC 0.. 120 [weeks] 00
SSD90 Series
FUNCTIONS
B35E-C
B30E-A
B34E-A
Outputs
Inputs
Options
B50E-A B55E-C
door
switch
RS485
* In the models B50 and B55 the defrost
relay is on voltage free contacts.
