2.1 Energy set & Diagnostic
Readout
1. charger plug/extension cord
2. carrying handle
3. key set receptacle/power switch
4. energy indicator
5. Self-Test button
6. charge level indicator lights
2.2 Control centre (handlebar)
1. Variable Power Control (twist throttle)
2. Variable Power Control cable
3. grip
4. rear derailleur gear shifter (Grip Shift)
5. shifter cable
6. shifter adjusting barrel
7. rear brake lever
8. front brake lever
9. brake adjusting barrel
10. stem height adjuster bolt
11. handlebar clamp bolts
12. brake sensor wire
13. safety switch
FIGURE 2C
FIGURE 2B
FIGURE 2D
