ATTACH THE BRIDLE TO THE
FORWARD BEAM
BRIDLE OPERATION RELAY
Lay out of: Skipper's cabin
1 - Handle position (The handle is
used to disengage the chain rim
brake and to haul in the anchor
manually in the case of electrical
breakdown)
2 - Drum head
3 - Chain lifter 10mm diameter
4 - Remote control
5 - Handle
6 - Clench
7 - Bow fitting
8 - Windlass 12V 1000W
WINDLASS CIRCUIT
BREAKER - 100A
(STARBOARD AFT
CABIN)
ANCHORING
