Lagoon 421 - Waste Water System

LAGOON 421
PLUMBING
70
WASTE WATER SYSTEM
WASHROOM
Drain plug -
Shower draining
Washbasin draining
1- Switches - Shower pump
2 - Shower pump - 12V
Lay out of: Passageway - Port and star-
board
Hand spray evacuation valve
Lay out of:
Aft cabins
Galley
Sink draining
watertight compartment - Port and star-
board
1- Drainage - Forward compartment
2 - Drainage - Engine compartment
