Lagoon 421 - Standing Rigging

LAGOON 421
9
RIGGING
& SAILS
89
SHORT MAST
LONG MAST
Referen-
ce
Designation Number Diameter (mm) Length (m)
1 Forestay 1 12 16.20
2 Guignol 1 8 12.02
3 Lozenge outside 2 10 13.16
4 Lozenge inside 2 7 7.11
5 Upper shroud 2 12 16.05
Referen-
ce
Designation Number Diameter (mm) Length (m)
1 Forestay 1 12.7 17.07
2Diamond back 2 10 9.43
3 Low diamond 2 10 9.42
4 Lower shroud 2 10 10.44
5 Upper shroud 2 12.7 16.92
