Lagoon 46 - Page 74

12 V ELECTRICAL EQUIPMENT
72
ELECTRICITY
1 - Switch of the inverter.
2 - Automatic breaker of the inverter.
3 - 12 V / 110 V - 220 V inverter.
4 - 12 V service batteries.
5 - Battery chargers.
31 2
7
6
8 9 10
6 - Electrical panel.
7 - Cut out coupling / batteries + port engine.
8 - Boat and starboard engine cutouts.
9 - Solar panels.
10 - Automatic breaker of the solar panels.
