Lagoon 46 - 12 V Circuit; Inverter System

ELECTRICITY
73
7
ELECTRICITY
The 12 V consuming appliances circuit breakers are located in a locker
to the left of the companionway in the starboard float.
They can be wound by pressing a black lug.
n 7.2 Inverter
The boat is optionally equipped with a 12 V / 110 V - 220 V / 2000 Va
inverter located in a cupboard to the right of the companionway in the
starboard float.
The inverter supplies the sockets with 110 V - 220 V.
The inverter power switch is located in the companionway in the star-
board float.
Check that the switch on the inverter is in REMOTE position in order for
the main switch to be turned on.
n 7.3 Solar panels (option)
The boat may be optionally equipped with solar panels (4 x 120 W).
In case of solar panel malfunctioning, check the automatic breaker
located in the starboard engine compartment.
n 7.1 12 V circuit
The main domestic circuit is supplied in 12 V.
The service batteries are located in the starboard engine compartment.
The generator battery (optional extra) is located in the central locker of
the forward swim deck.
The starboard engine battery and the port engine battery are located in
their respective engine compartments.
The starboard engine and on-board cut-outs are located in the star-
board engine compartment.
The port engine cut-out is located in the port engine compartment.
For safety reasons, a coupling system for the engine batteries (cut-out
located in port engine compartment) allows the engine to start if the
relevant battery is faulty.
The generator includes its own cut outs located in the central locker of
the forward swim deck.
BATTERY CHARGERS
The batteries can be charged either by the engine alternator or by the
110 V - 220 V / 12 V - 60 A battery charger.
According to the lay out, the boat may optionally be fitted with an extra
110 V - 220 V / 12 V - 40 A charger.
The battery chargers are located in the starboard engine compartment.
SUPPLY OF THE CHARGERS
Select the power supply source (generator or shore power socket)
from the touch control screen at the chart table.
RECOMMENDATION
Check the battery charge during the use of the
inverter.
