Tool rest
Two tool rests are provided. A 10” tool rest that can move to most positions on the
lathe bed is provided for normal spindle turning and a second tool rest is provided for
large bowl turning.
Electrical system
The electrical control system is housed in a box that is on an extension cable. This
allows the controls to be moved to a position to suit the job that you are doing. . The
main on/off switch is located on the front of the headstock. A plug and socket are
provided on the back of the machine to enable quick connection and disconnection of
the electrical supply. No cable is supplied, as the length of the cable will be dependant
on your installation. The lathe has a 3 HP Baldor 220-volt single or 3-phase
Optional copy attachment.
The copy attachment fits at the back of the lathe and will accept flat templates or
round masters.
Dust collection.
The dust collection port is located at the back of the copy attachment. You will need a
dust collection system with a minimum airflow of 65 feet / second and 1000 cubic
feet per minute.
Optional fluting or spiral fluting attachment.
The flutes are produced by cutters that rotate in a router drill or similar tool [not
provided] that is fitted to the copy carriage. The lathe spindle is detached from the
motor and attached via a set of gears that rotate the spindle as the copy carriage is
moved along the bed of the lathe.
Optional bed extensions
Bed extensions can be added to the end of the bed to give addition length if required.
Where to locate your machine.
Before you remove your machine from the pallet select the area where you will use
your machine. There are no hard and fast rules for its location but below are a few
guidelines.
2/ There should be sufficient area at the back of the machine to allow access for
adjustments and maintenance to be conducted and if fitted you will need access to the
copy attachment which is located at the back of the machine.
3/ Adequate lighting. The better the lighting the more accurate and safely you will be
able to work
4/ Solid floor. You should select a solid flat floor, preferably concrete or something
similar.
5/ Close to power source and dust collection.
6/ Allow an area for the storage of blanks and finished panels.
