Noise emission
Notes concerning noise emission
Given that there exists a relationship between noise level and exposure times, it is not
precise enough to determine the need for supplementary precautions. The factors
affecting the true level of exposure to operators are clearly the amount of time exposed,
the characteristics of working environment other sources of dust and noise etc. For
example, adjacent machines in other words the level of ambient noise. It is possible that
exposure level limits will vary from country to country.
Machine Specification
Distance between centres
50” [1270mm]
Distance between centres with extended
bed Factory fitted option
70”* [1778mm] and 100”* [2540mm]
Distance between spindle centre and bed
12” [305mm] with a section that can
be removed to allow 48”[1219mm]
diameter bowels to be turned.
Distance between ground and spindle
centre
45” [1150mm]
Weight
560 lb [254 kg]
Tail Stock
Body material
Cast iron
Ram [Quill] diameter
1 27/32” [47mm]
Ram [Quill] travel
5 33/64” [140mm]
Ram [Quill] lead screw
ACME
Ram [Quill] graduations
1/16” for full 5 33/64” travel
Ram internal taper
Morse taper 3
Hole diameter through ram
5/16” [8mm] diameter
Head Stock
Head stock material
Cast iron
Bearings
4 bearing spindle sealed for life
Drive type
Pulleys / V belt
Spindle speed
0-3500 / 0-2820 / 0-1200 / 0-450 rpm
Rotation
Forward / reverse
Motor
1 1/5 hp 1 phase 220V or 3 hp 3-phase
factory fitted option. All motors with
internal overload protector
Micro switch on access door to pulleys
Yes
Internal taper
Morse taper 3
Spindle thread
45mm x 4.5mm pitch
Indexing head
24 positions
Spindle lock
Yes
Tool rest
Swing over tool rest base
Swing over bed
8 15/32” [215mm]
12” [305mm]
