Laing E1 Series - Specifications and Unpacking; E Series Specifications; Unpacking Instructions

E Series Specications
1
Unpacking
When unpacking the unit inspect carefully for any damage that may have occurred during transit. Check for loose,
damaged, or missing parts. Do not attempt to assemble or operate pump if any parts are missing or damaged.
General Safety Information
1. Know the pump application, limitations and potential hazards.
Pump should only be used with liquids compatible with pump component materials. Do not use to pump ammable or
explosive uids such as gasoline, fuel oil, kerosene, etc. Do not use in ammable and/or explosive atmospheres.
Materials of Construction (wetted parts)
Part
Pump Housing
“O” Ring
Impeller
Bearing
All Other Wetted Parts
Plastic Housing Models
Nylon/PPO
EPDM or Viton
Nylon/PPO
Carbon/Allumina Ceramic
316 Stainless Steel or Plastic
Non Plastic Housing Models
316 Stainless Steel, Metal, Brass
EPDM or Viton
Nylon/PPO
Carbon/Allumina Ceramic
316 Stainless Steel or Plastic
E1, E3, E5, E10, and E14 Series
E Series Specifications
M
F
Te
in
luid
mp
Max
Fluid
Temp
Max
Fluid
Temp
Max
Pressure
M
Pres
ax
sure
A
Max
mbient
Temp
Max
Ambien
Temp
t
Min
Storage
Temp
Min
Storag
Temp
e Voltag
Rang
e
e Freq
Rated
Wattage Max RPMs
(°C) (°C) (°F) (bar) (PSI) (°C) (°F) (°C) (°F) (V) (max.: W)
E1 Brass 10 95 203 10.32 150 50 122 -30 -22 100-240V 50-60Hz 12 3600
E1 Plastic 10 60 140 3.5 51 50 122 -30 -22 100-240V 50-60Hz 12 3600
E3 Brass 10 95 203 10.32 150 50 122 -30 -22 100-240V 50-60Hz 27 4800
E3 Brass Vario 10 95 203 10.32 150 50 122 -30 -22 100-240V 50-60Hz 27 4800
E3 Plastic 10 60 140 3.5 51 50 122 -30 -22 100-240V 50-60Hz 27 4800
E5 Strong Brass 10 80 176 10.32 150 50 122 -30 -22 100-240V 50-60Hz 50 5340
E5 Strong Plastic 10 80 176 3.5 51 50 122 -30 -22 100-240V 50-60Hz 50 5340
E10 Brass 10 95 203 4.14 60 50 122 -30 -22
115V 50-60Hz 80 3100
E10 Plastic 10 55 131 2 29 50 122 -30 -22
115V 50-60Hz 80 3100
E10 Cast Iron flanged 10 95 203 4.14 60 50 122 -30 -22
115V 50-60Hz 80 3100
E10 Brass 10 95 203 4.14 60 50 122 -30 -22
230V 50-60Hz 80 3100
E10 Plastic 10 55 131 2 29 50 122 -30 -22
230V 50-60Hz 80 3100
E10 Cast Iron flanged 10 95 203 4.14 60 50 122 -30 -22
230V 50-60Hz 80 3100
E14 Plastic 10 55 131 2 29 50 122 -30 -22
230V 50-60Hz 110 2700
Housing Codes
BCS 1/2”
BCT 1/2”
BCS 3/4”
SCT 3/4”
BCF
Material/Connection
Brass 1/2” (5/8”) Sweat
Brass 1/2” (5/8”) Threaded Female NPT
Brass 3/4” Sweat
Stainless 3/4” Threaded Female NPT
Bronze 3/4” Flanged
Available On
E1, E3, E10
E1, E3
E1, E3, E10
E10
E10
HCF
Cast Iron 3/4” Flanged
E10
NCH 1/2”
NCH 3/4”
NCT 3/4”
NCT 3/4”
NCH 1”
Noryl 1/2” OP Hose
Noryl 3/4” OP Hose
Noryl 1/2” Threaded Male NPT
Noryl 3/4” Threaded Male NPT
Noryl 1” OP Hose
E1, E3, E5
E1, E3, E5, E10
E1, E3, E15
E1, E3, E5, E10
E10
