List of Figures
4 - 1FIGURE 4.1: SIMPLIFIED EMS POWER SUPPLY
3 - 12FIGURE 3.15: REMOTE SENSING
3 - 11FIGURE 3.14: SERIES OPERATION, MASTER/SLAVE
3 - 10FIGURE 3.13: SERIES OPERATION
3 - 10FIGURE 3.12: PARALLEL OPERATION, MASTER/SLAVE
3 - 9FIGURE 3.11: PARALLEL OPERATION
3 - 8
FIGURE 3.10: REMOTE PROGRAMMING BY EXTERNAL CURRENT,
CURRENT MODE
3 - 8
FIGURE 3.9B: REMOTE PROGRAMMING BY EXTERNAL VOLTAGE,
CURRENT MODE (AS PER OPTION)
3 - 7
FIGURE 3.9A: REMOTE PROGRAMMING BY EXTERNAL VOLTAGE,
CURRENT MODEL
3 - 7
FIGURE 3.8: REMOTE PROGRAMMING BY EXTERNAL RESISTANCE,
CURRENT MODE
3 - 6
FIGURE 3.7: REMOTE PROGRAMMING BY EXTERNAL CURRENT, VOLTAGE
MODE.
3 - 5
FIGURE 3.6B: REMOTE PROGRAMMING BY EXTERNAL
VOLTAGE,VOLTAGE MODE (AS PER 0 - 10V OPTION).
3 - 5
FIGURE 3.6A: REMOTE PROGRAMMING BY EXTERNAL VOLTAGE,
VOLTAGE MODE
3 - 4
FIGURE 3.5: REMOTE PROGRAMMING BY EXTERNAL RESISTANCE,
VOLTAGE MODE
3 - 3FIGURE 3.4: LOCAL PROGRAMMING
3 - 3FIGURE 3.3 REAR PANEL “D” CONNECTOR
3 - 2FIGURE 3.2: OPERATING MODES
3 - 1FIGURE 3.1: FRONT PANEL, (5KW MODEL SHOWN)
2 - 2FIGURE 2.1: DELTA TO WYE CONNECTION
List of Tables
5 - 3TABLE 5.1: TROUBLESHOOTING GUIDE
3 - 13TABLE 3.3: RECOMMENDED WIRE SIZE FOR LOAD CONNECTION
3 - 3TABLE 3.2: TB1/J1
3 - 1TABLE 3.1: FRONT PANEL CONTROLS AND LEDS
1 - 7TABLE 1.7: MODEL NUMBER
1 - 5TABLE 1.6: PHYSICAL SPECIFICATIONS
1 - 5TABLE 1.4: REMOTE PROGRAMMING ACCURACY
1 - 4TABLE 1.3: RIPPLE FOR THREE PHASE
1 - 2TABLE 1.1: INPUT POWER
