Lamona FLM8702 - Operating the Washing Machine; Washing Machine Overview and Installation; Control Panel Explanation

8
www.howdens.com
2 3 4 5
1
1. Programme selection knob
2. Display
3. Temperature adjustment button
4. Spin adjustment button
5. Delay start button
6. Rapid wash button
7. Pre wash button
8. Start / pause button
9. Delay timer indicator
10.Rapid wash indicator
11. Prewash indicator
12. Start / pause indicator
109 11 12
6 7 8
Detergent
drawer
Programme
Dial
Display
Adjustable
foot x4
Pump filter cover
Water inlet
valve
Drain hose
(1.5m)
Power cable
and plug
IMPORTANT: Remove all 4x transit bolts
Minimum Clearances
20mm 20mm
10 - 20mm
Front
Operating the washing machine
Washing machine overview and Installation
Control panel
