To Next PageTo Next PageWhat to do if my Lamona LAM2377 does not operate?
If your Lamona Ventilation Hood isn't working, the main fuse might be defective or tripped. Check the fuses in the fuse box and replace or reset them if needed. Also, ensure that all power connections are properly connected.
Why does my Lamona Ventilation Hood have poor extraction?
Poor extraction in your Lamona Ventilation Hood can stem from a few issues. The ducting might be the wrong size, or there could be obstructions in the ducting or outlet. Also, exceeding the recommended number of 90° ducting bends or the ducting running too long can reduce efficiency. Make sure the cooker hood is switched on 10 minutes before and after cooking. To resolve this: * Check that the cooker hood is using the correct size ducting. * Check there are no restrictions within ducting or outlet. * Check that the installation does not exceed the minimum recommended number of 90° bends. * Check that the installed ducting does not exceed the recommended run length for the model installed. * Ensure the cooker hood is switched on 10 minutes before and after cooking.
What to do if my Lamona LAM2377 Ventilation Hood motor is on but the fan isn't efficient?
If the motor of your Lamona Ventilation Hood is running but the fan isn't as efficient, clogged filters could be the cause. Check the grease and carbon filters (if fitted) and ensure any venting is not obstructed. Clean the grease filters with warm water and mild detergent, and replace the carbon filters if fitted.
Why do smells linger when my Lamona LAM2377 works normally?
If your Lamona Ventilation Hood is working normally, but smells are lingering, it could be due to clogged filters, which reduce the product’s efficiency and may cause unwanted smells. To fix this, clean the grease filter(s) with warm water and mild detergent and replace the carbon filters, if fitted.
How to fix a Lamona Ventilation Hood when the light works but the fan doesn't?
If the light on your Lamona Ventilation Hood is working, but the fan isn't, it's possible that the motor temperature has exceeded its limit, and the thermal fuse has tripped. To resolve this, switch off the cooker hood and allow it to cool down so the fuse will auto reset. Also, check the filter conditions and clean or replace them as required.
Why is condensation collecting on my Lamona LAM2377 Ventilation Hood?
Condensation on your Lamona Ventilation Hood surfaces may occur when cooking with pans using a large amount of water, which quickly creates vapor and steam. This can collect onto the cold metallic surfaces of the appliance. To minimize this: * Increase the ambient temperature of the kitchen. * Check there is adequate ventilation. * Reduce the duration of cooking if possible. * Simmer once boil is achieved. Use lids on pans to reduce steam being released reducing subsequent condensation.
Why is my Lamona Ventilation Hood so noisy?
If your Lamona Ventilation Hood is making excessive noise, several factors could be responsible. * Incorrectly sized ducting may have been installed: Ensure the correct size ducting is installed. * The ducting and/or outlet might be blocked: Make sure the ducting and outlet are free from any obstructions. * Too many 90° ducting bends: Verify that the installation doesn't exceed the recommended number of 90° bends. * The hood may not be correctly secured to the wall: Ensure the hood is properly installed to the wall. * Something may have fallen into the fan area: Check the fan area for any cabling or debris. * (In recirculation mode) The ful e vents/grilles are obstructed: Ensure the ful e vents/grilles are not obstructed. * The cooker hood cabinet may lack a hole for air to ...
Explanation of the various symbols used throughout the user manual for warnings and notes.
Highlights the key features and technologies incorporated into the cooker hood.
Ensuring the appliance is used only for domestic extraction purposes and not for other uses.
Guidelines on keeping children and vulnerable individuals safe around the appliance.
Essential safety precautions for operating the cooker hood, including electrical safety.
Specific safety advice for electrical connections and maintenance.
Detailed instructions and safety requirements for connecting the appliance to the mains electricity.
Precautions regarding ventilation and air quality when using the cooker hood with other heating appliances.
Diagram and labels identifying the main components of the cooker hood.
Explanation of the functions and layout of the cooker hood's control panel.
Explanation of condensation on metal surfaces during cooking and factors affecting it.
Detailed guide on using the control panel buttons for fan speed and lighting.
Instructions for cleaning the external surfaces of the cooker hood using mild detergent.
Specific advice on cleaning and maintaining the stainless steel finish to prevent marks.
Guidance on cleaning and maintaining the grease filters for optimal performance.
Step-by-step visual guide on how to remove the grease filters for cleaning.
Information on using, replacing, and purchasing carbon filters for recirculation mode.
Instructions regarding the replacement of LED lamps, emphasizing professional service.
Diagnosing and resolving issues where lights work but the fan does not.
Troubleshooting steps for when the appliance lamps are not functioning.
Identifying causes and solutions for reduced fan efficiency.
Addressing persistent smells after the cooker hood has operated.
Steps to take if the cooker hood fails to power on or function.
Troubleshooting common causes of noise from the cooker hood.
Diagnosing and fixing issues related to inadequate air extraction.
Explaining and resolving condensation issues on the cooker hood.
Instructions for recycling and disposing of the appliance's packaging materials.
Guidance on the safe and environmentally responsible disposal of the used appliance.
Details of the manufacturer's guarantee coverage and terms for UK and ROI.
Steps and contact information for reporting issues or requesting service.
Information on the availability of genuine spare parts for the appliance.
Explanation of the various symbols used throughout the user manual for warnings and notes.
Highlights the key features and technologies incorporated into the cooker hood.
Ensuring the appliance is used only for domestic extraction purposes and not for other uses.
Guidelines on keeping children and vulnerable individuals safe around the appliance.
Essential safety precautions for operating the cooker hood, including electrical safety.
Specific safety advice for electrical connections and maintenance.
Detailed instructions and safety requirements for connecting the appliance to the mains electricity.
Precautions regarding ventilation and air quality when using the cooker hood with other heating appliances.
Diagram and labels identifying the main components of the cooker hood.
Explanation of the functions and layout of the cooker hood's control panel.
Explanation of condensation on metal surfaces during cooking and factors affecting it.
Detailed guide on using the control panel buttons for fan speed and lighting.
Instructions for cleaning the external surfaces of the cooker hood using mild detergent.
Specific advice on cleaning and maintaining the stainless steel finish to prevent marks.
Guidance on cleaning and maintaining the grease filters for optimal performance.
Step-by-step visual guide on how to remove the grease filters for cleaning.
Information on using, replacing, and purchasing carbon filters for recirculation mode.
Instructions regarding the replacement of LED lamps, emphasizing professional service.
Diagnosing and resolving issues where lights work but the fan does not.
Troubleshooting steps for when the appliance lamps are not functioning.
Identifying causes and solutions for reduced fan efficiency.
Addressing persistent smells after the cooker hood has operated.
Steps to take if the cooker hood fails to power on or function.
Troubleshooting common causes of noise from the cooker hood.
Diagnosing and fixing issues related to inadequate air extraction.
Explaining and resolving condensation issues on the cooker hood.
Instructions for recycling and disposing of the appliance's packaging materials.
Guidance on the safe and environmentally responsible disposal of the used appliance.
Details of the manufacturer's guarantee coverage and terms for UK and ROI.
Steps and contact information for reporting issues or requesting service.
Information on the availability of genuine spare parts for the appliance.
General| Type | Chimney |
|---|---|
| Width | 60 cm |
| Noise Level | 65 dB |
| Number of Speeds | 3 |
| Lighting | LED |
| Number of Motors | 1 |
| Material | Stainless Steel |
| Filters | Aluminum |
