! Remove the 4 transportation
screws (A) on the back and
remove the 4 flat washers, rubber
bungs and plastic spacer tubes
(B) as illustrated in figure 1.
!
During the removal of the screws
occasionally spacer tubes fall
inside the product, these can be
remove by tilting the product forward
and recovering them from the floor
or inside the base of the machine.
! Cover the open transportation screw
holes with the 4 plastic caps
included in the instruction bag.
! Place the corrugated plastic sheet,
found on top of the appliance during
the unpacking process, into the base
of the appliance as shown in figure 2.
