7.1 Flame Scanner Testing Device
Fig. 7-1 Flame Scanner Testing Device FFP30
Fig. 7-2 1. (1) Positions of the internal jumper IR + UV
Fig. 7-3 Dimensional drawing FFP30
A, B, C Threaded receptacle for F200K, F300K
Plug-in receptacle for FFS05, FFS06, FFS07, FFS08, F200K
D Changing battery (9 V, 500 mA - turn left to open housing)
E Toggle switch
