3 Product Description
DANGER!
High voltage on the bare ignition electrode!
Pilot burner is only permitted to be operated with correct earthing.
With version C in particular there is a danger of death when removing or omitting the earth-
ing, the housing earthing must be connected directly to the ignition transformer earthing!
In the event of damage to the earthing insulation, the device should be shut down; further
operation without repair is not permitted.
NOTICE
Higher pressure ratings can be realised by connecting a restrictor upstream.
Cable lengths max. 20 m (65.62 ft)
Cable cross-section 1 x 1.0 mm
2
(1 x 17 AWG)
Isolation Silicone, red-brown
Temperature range -60 ... +180 °C (-76 ... 356 °F)
Design C: Connection of external ignition transformer to the ignition electrode
Design C: Connection of external flame scanner to the ionisation electrode
(same procedure as for B)
Design C: Ground cable
Recommended cable specifications
Cable lengths Max. 200 m (656.168 ft)
Cable cross-section 1 x 1.5 mm
2
(1 x 15 AWG) and/or according to regional
regulation
Connection: GFI48 gas
Gas type Natural gas or propane
Flow rate (gas quantity) Natural gas: 8.0...15.0 m
3
/h (10.46 ... 19.61 yd
3
/h)
Propane: 3.2...6.0 m
3
/h (4.18 ... 7.84 yd
3
/h)
Operating pressure Min. 50 mbar (0.725 psi)
Max. 200 mbar (2.90 psi)
Connection: GFI70 gas
Gas type Natural gas or propane
Flow rate (gas quantity) Natural gas: 15.0 ... 30.0 m
3
/h (19.61 ... 39.23 yd
3
/h)
Propane: 6 ... 12.0 m
3
/h (7.84 yd
3
/h ... 15.69 yd
3
/h)
Operating pressure Min. 50 mbar (0.725 psi)
Max. 200 mbar (2.90 psi)
Connection: GFI89 gas
Gas type Natural gas or propane
Flow rate (gas quantity) Natural gas: 35.0...70.0 m
3
/h (45.77 ... 91.55 yd
3
/h)
Propane: 14...28.0 m
3
/h (18.31 ... 36.62 yd
3
/h)
Operating pressure Min. 50 mbar (0.725 psi)
Max. 200 mbar (2.90 psi)
To Next Page
