6 Commissioning
6.3 Significance of Digital Display
 = Signal present
 = Signal not present
On a 4 channel unit:
Turn selector switch (1) to DIGITAL INPUTS
On a 5 channel unit:
Turn selector switch (1) to channel 5 display
and
select acceptance (3)
 the display shows status of the digital inputs
 – = input not activated
  = input activated
