Land Pride FSP700 - Lubrication Points

23
Section 5: Maintenance
FSP500, FSP700 & FSP1000 Broadcast Spreaders 309-065M
Table of Contents
11/29/18
Driveline
Grease all knuckle points daily. This includes the zerks, and
tubes of the driveline shaft.
15357
Lubrication Points
Gearbox
Type of Lubrication:
Use Lithium Base gun grease, Grade 2 rated for gearbox
application.
Quantity = 3 pumps every 25 hours.
NOTE: DO NOT OVERFILL, SEAL DAMAGE CAN
OCCUR. There is no purge hole in gearbox!
Gearbox can be checked for grease level by
removing grease zerk. Grease should be up to
bottom of zerk hole when full.
15356
25
Hours
Seasonally
50
Hrs
Multi-purpose
spray lube
Multi-purpose
grease lube
Multi-purpose
oil lube
Intervals in hours at which
lubrication is required
Lubrication
Legend
