LANDA PE • 8.913-998.0 • Rev. 03/12
17
PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
32 8.712-398.0 Nozzle, Brass, Soap 1
34 9.802-146.0 Swivel, 1/2" MP x 3/4" GHF 1
35 9.802-516.0 Strain Relief, Plastic, LQ Tite
(3-11024) 1
9.802-524.0 ▲ Locknut, 1/2" (3-11024) 1
36 Overload, See Specifi cations Pages
37 Contactor, See Specifi cations Pages
38 9.802-759.0 Screw, 10/32" x 1/2"
(3-11024D; 4-02007A) 4
(4-30024A) 7
(4-20024B,C; 4-30024B,C;
5-30024B,C) 5
39 9.802-695.0 Nut, 10/32" Keps (4-20024A,
4-20024B,C; 4-30024B,C;
5-30024B,C) 6
(3-11024D) 7
(4-30024A) 10
40 8.707-254.0 Pump Protector, 3/8", PTP
( All Models Except 3-11024) 1
9.804-025.0 Pump Protector 1/4” 145°
(3-11024) 1
41 Pump, See Specifi cations Pages
42 Motor, See Specifi cations Pages
43 9.802-710.0 Bolt, 5/16" x 1", NC HH
(3-11021) 4
9.802-722.0 Bolt, 3/8" x 1-1/4", NC HH
(All Models Except 3-11021) 4
44 8.718-980.0 Washer, 5/16" Flat (3-11021) 4
9.802-807.0 Washer, 3/8" Flat (All Models
Except 3-11021) 4
45 9.802-776.0 Nut, 5/16" ESNA (3-11021) 4
9.802-779.0 Nut, 3/8" ESNA (All Models
Except 3-11021) 4
46 8.718-980.0 Washer, 5/16" Flat 6
47 9.802-776.0 Nut, 5/16" ESNA, NC 3
48 8.718-674.0 Bolt, 3/8-16 X 2-1/4",GR8.2
Whiz Loc 8
49 9.802-802.0 Washer, 1/4" Flat, SAE 4
50 9.802-773.0 Nut, 1/4" ESNA, NC 2
51 8.718-618.0 Bolt, 5/16" x 3/4", NC HH 1
52 8.719-905.0 Back Plate, Belt Guard,
Large (All Models Except
3-11024) 1
8.911-285.0 Back Plate, Belt Guard,
Small (3-11024) 1
53 8.706-655.0 Belt Guard, Small
(PE3-11024) 1
8.706-656.0 Belt Guard, Large (PE) 1
54 9.802-710.0 Bolt, 5/16" x 1" NC, HH 2
55 8.900-246.0 ▲ Label, PE 1
ITEM PART NO. DESCRIPTION QTY
56 8.900-403.0 ▲ Label, 3-1100 1
8.900-409.0 ▲ Label, 4-2000 1
8.900-411.0 ▲ Label, 4-3000 1
8.900-414.0 ▲ Label, 5-3000 1
57 Pump Bushing, See Specifi cations Pages
58 Motor Bushing, See Specifi cations Pages
59 Motor Pulley, See Specifi cations Pages
60 Pump Pulley, See Specifi cations Pages
61 Belt, See Specifi cations Pages
62 9.802-478.0 Lid, Plastic, Carlon (3-11024) 1
63 8.716-271.0 Enclosure, Fiberglass, Nema 4X
(except 3-11024, 4-30024A) 1
9.802-476.0 Box, Plastic 10" x 8" x 6"
(4-30024A) 1
64 8.900-315.0 Label, OFF/ON for Push Button
(All Models Except 3-11024) 1
65 9.800-016.0 Label, Disconnect
Power Supply 1
66 9.803-974.0 Switch, Green Push Button, 1
CH E22PB3 (All Models
Except 3-11024)
67 9.802-535.0 Block, Contact, N/O, CH E22B2
(All Models Except 3-11024) 1
68 9.803-973.0 Switch, Red Push Button, CH
E22EB2(All Models Except
3-11024) 1
69 9.802-534.0 Block, Contact, N/C, CH 1
E22B1
(All Models Except 3-11024)
70 9.802-457.0 Din Rail (All Models Except
(3-11024D) 4"
71 9.802-477.0 Box, Electric (3-11024 only) 1
72 9.800-034.0 Label, Clear Lexan 1
73 9.802-518.0 Strain Relief, STRT, LQ Tite
Large, 3/4" (3-11024) 1
9.802-526.0 ▲ Locknut, 3/4” (3-11024) 1
74 9.802-450.0 Switch, 2 Pos., 1-3 PH
(3-11024) 1
75 9.802-720.0 Bolt, 3/8" x 1", NC 4
76 9.802-789.0 Nut, 3/8" Hex NC 2
77 9.800-040.0 Label, Ground 1
78 8.706-860.0 Tee, 1/2" (4-20024,
4-30024, 5-30024) 1
79 9.802-259.0 Hose, 1/2" Push-On 1.3 ft
(4-20024, 4-30024, 5-30024)
80 9.802-151.0 Swivel, 1/2" JIC Fem,
Push-On (4-20024,
4-30024, 5-30024) 2
