LANDA PE • 8.913-998.0 • Rev. 03/12
OPERATOR’S MANUAL
PRESSURE WASHER
18
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
81 9.802-131.0 Elbow, 1/2" JIC x 1/2", 90° 1
(4-20024, 4-30024, 5-30024)
82 8.918-424.0 Hose, 3/8" x 25", 2 Wire,
Pressure Loop (4-20024,
4-30024, 5-30024) 1
83 9.802-039.0 Elbow, 1/2" JIC x 3/8", 90°
(4-20024, 4-30024, 5-30024) 1
84 9.802-036.0 Nipple, 1/2" JIC x 3/8", Pipe
(4-20024, 4-30024, 5-30024) 1
85 8.705-974.0 Nipple, 3/8", Hex (4-20024,
4-30024, 5-30024) 1
86 9.802-870.0 Block, Unloader, 3/8" x 3/8",
1.25, Steel (4-20024,
4-30024, 5-30024) 1
87 9.802-129.0 Elbow, 1/2" x 3/8", 90°
(4-20024, 4-30024, 5-30024) 1
88 9.802-728.0 Bolt, 3/8" x 2", NC HH
(4-20024, 4-30024, 5-30024) 2
89 9.802-744.0 Bolt, 10mm x 20mm, HH
(All Models except 3-11024) 4
9.802-741.0 Bolt, 8mm x 16mm HH
(3-11024) 4
90 9.802-816.0 Washer, 7/16" Lock, Split
(All Models except 3-11024) 4
9.802-814.0 Washer, 3/8", Lock,
Split Ring (3-11024) 4
91 9.802-811.0 Washer, 3/8" x 1-1/2",
Fender
(All Models Except 3-11024) 6
8.719-000.0 Washer, 5/16” x 1-1/4”
Fender (3-11024) 6
92 9.802-526.0 Locknut, 3/4" (4-30024A) 2
93 9.803-098.0 Hanger, Hose & Wand 1
94 9.802-778.0 Nut, 5/16" Whiz Loc, Flange 2
95 9.802-518.0 ▲ Strain Relief, Watertite
(3-11024D; 4-20024A,B,C;
4-30024B,C; ) 1
9.803-279.0 ▲ Strain Relief, 1" Metal
(4-30024A, 5-30024C) 1
8.716-565.0 Strain Relief, 1" (5-30024B) 1
96 9.803-280.0 Locknut, 1"(4-30024A;
5-30024B,C) 1
97 9.802-521.0 Strain Relief, 3/4 Watertight
(4-30024A) 1
98 9.802-518.0 Strain Relief, 3/4 Watertight
Plastic (4-30024A) 1
99 9.800-049.0 Label, Manufacturer’s
Cleaning Solution 1
100 8.900-814.0 Label (PE) 1
101 9.803-032.0 Stand-Off Electrical Box
(4-30024A) 1
102 8.718-708.0 Eye Bolt, 1/4" x 1" 2
103 8.719-073.0 Spring, Pull, Belt Guard 1
ITEM PART NO. DESCRIPTION QTY
104 9.800-040.0 ▲ Label, Ground (Motor) 1
105 9.802-225.0 Chemical Injector Assy. 1
106 9.802-762.0 Screw, 10/32" x 1-1/4" 1
Ground
(All Models Except 3-11024D)
9.802-699.0 Screw, 10/32" x 3/4" Ground
(3-11024D) 1
107 9.800-013.0 Label, Indoor Use 1
▲ Not Shown
