LANDA PE • 8.913-998.0 • Rev. 03/12
23
PRESSURE WASHER
OPERATOR’S MANUAL
LD.1 PUMP EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
33 8.933-010.0 Crankshaft Seal 1
34* See Kits Below Plunger Nut 3
35* See Kit Below Copper Spacer 3
36*
See Kits Below Plunger, 15mm (3030) 3
See Kits Below Plunger, 18mm 3
(4020, 3025)
37*
See Kits Below Copper Spacer 3
38* See Kits Below O-Ring Ø1.78 x 5.28 3
39* See Kits Below Tefl on Ring 3
40* See Kits Below Plunger Rod 3
41 9.803-965.0 Connecting Rod Pin 3
42 9.803-966.0 Connecting Rod 3
43 9.803-218.0 Spring Washer 6
44 8.933-020.0 Connecting Rod Screw 6
45 9.803-202.0 Sight Glass 1
46 9.803-197.0 Gasket 1
47 9.803-968.0 Crankcase Cover 1
48 9.803-969.0 O-Ring Ø2.62 x 107.62
* Available in kit (See below)
REPAIR KIT
NUMBER 8.725-354.0 8.725-356.0 8.725-355.0 8.725-357.0 9.803-934.0 9.803-935.0 9.803-936.0 9.803-937.0
Kit Descrip-
tion
Plunger
Seal 15mm
LD-3030
Plunger
Seal 18mm
LD-3025
LD-4020
Complete
Seal
Packing,
15mm
LD-3030
Complete
Seal Pack-
ing, 18mm
LD-3025
LD-4020
Plunger
15mm
LD-3030
Plunger
18mm
LD-3025
LD4020
Complete
Valve
Plunger Oil
Seals
ITEM
NUMBERS
INCLUDED
3, 5, 7 3, 5, 7
3, 4, 5,
6, 7
3, 4, 5,
6, 7,
34, 35, 36,
37, 38
34, 35, 36,
37, 38
11, 12, 13 2
NUMBER
OF CYL-
INDERS
KIT WILL
SERVICE
33111163
