Landa PE4-2000 - Exploded View Parts Lists; Main Unit Parts Identification

LANDA PE • 8.913-998.0 • Rev. 03/12
OPERATOR’S MANUAL
PRESSURE WASHER
16
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 8.718-835.0 Nut, Jam, ESNA, NC, 5/8" 2
2 9.802-810.0 Washer, Flat, SAE, 5/8"
(PE4-3000) 8
(All Other PE Models) 8
3 9.802-271.0 Tire & Wheel Cmpl, Steel 6"
(All Models except 3-11024) 2
9.802-270.0 Wheel & Tire Assembly,
4" Tube, (3-11024) 2
4 8.920-250.0 Handle, Bumper, 1-1/4",
Chrome Plated 1
5 9.198-004.0 Washer, 3/8" Uss F/w Zinc
(PE3-11024) 20
(All Other PE Models) 22
6 9.802-779.0 Nut, ESNA, NC, 3/8"
(PE3-11024) 16
(All Other PE Models) 14
7 9.802-733.0 Bolt, 3/8" x 3-1/2", Tap 2
8 8.719-905.0 Bracket, Belt Tension 1
9 9.802-771.0 ▲Screw, 10/32” x 3/4”
(4-20024A) 3
10 8.911-293.0 Bracket, Foot, Black 1
11 8.906-774.0 Foot Assembly
(Items 11-17) 2
12a 8.718-684.0 Bolt, 3/8" x 5", NC 2
12b 9.802-817.0 Washer, 3/8" x 1", Steel 2
13 9.802-066.0 Pad, Soft Rubber 2
14 9.802-819.0 Washer, 2-1/2" x 7/16",
Flat Washer 2
15 8.719-954.0 Tube, Foot, Bolt PC 2
16 8.719-091.0 Spring, Foot, Compression 2
17 8.706-557.0 Bellows, Leg (Boot) 2
18 8.911-289.0 Frame, Black, Welded
(3-11024D) 1
8.911-297.0 Frame, Large, Black,
Welded (All Other Models) 1
19 8.900-818.0 Label, PE 1
20 8.719-904.0 Handle, 1-1/4", Chrome 1
22 9.802-171.0 Nipple, 3/4" x 3/8" Male 1
23 8.911-244.0 Bracket, Electrical Box (All
Models except 4-30024A) 1
8.911-245.0 Bracket, Electrical Box
(4-30024A) 1
24 8.932-969.0 Label, Warning Service
Cord 1
25 8.932-993.0 Cushion, Pump 2
26 Unloader, See Specifi cations Pages
ITEM PART NO. DESCRIPTION QTY
27 9.802-431.0 Cord, w/Gfci, 120V/20 Amp,
36' (3-11024D) 1
9.802-429.0 Cord, Service 12/4
(4-20024B,C; 4-30024C;
5-30024C) 15 ft
9.802-430.0 Cord w/GFCI, 240V/30 Amp
36' (4-20024A) 1
9.802-437.0 Cord, Service,10/4
(4-30024B) 15 ft
9.802-434.0 GFCI, 240V, 40A, 1 PH, 37'
Cord (4-30024A) 1
9.802-426.0 Cord, Service, 8/4
(5-30024B) 15 ft
28 9.802-436.0 Cord, Service, SEO, 10/3 2.75 ft.
10/3 (4-20024A)
9.802-427.0 Cord Service SEO, 12/3 2 ft
(3-11024D)
9.802-429.0 Cord, Service, SEO, 12/4 2.75 ft
(4-20024B,C; 4-30024C;
5-30024C
9.802-437.0 Cord, Service, SEO, 2.75 ft
10/4
9.802-425.0 Cord, Service SEO 8/3 4.66 ft
(4-30024A)
9.802-426.0 Cord, Service SEO, 8/4 2.75 ft
(5-30024B)
29 9.802-518.0 Fitting, STRT, LQ Tite, Plastic
(4-20024A,B,C; 4-30024B,C;
5-30024C) 2
9.802-521.0 Strain Relief, Water Tight
(5-30024B) 2
30 9.802-064.0 Grommet, Rubber, 1/8" 5
31 8.712-345.0 Nozzle, SAQC MEG 0004
Red (4-30024 ) 1
8.712-346.0 Nozzle, SAQC MEG 1504
Yellow (4-30024 ) 1
8.712-347.0 Nozzle, SAQC MEG 2504
Green (4-30024 ) 1
8.712-348.0 Nozzle, SAQC MEG 4004
White (4-30024 ) 1
8.712-357.0 Nozzle SAQC MEG 0005.5
Red (3-11024, 5-30024) 1
8.712-358.0 Nozzle, SAQC MEG 15055
Yellow (3-11024, 5-30024) 1
8.712-359.0 Nozzle, SAQC MEG 25055
Green (3-11024, 5-30024) 1
8.712-360.0 Nozzle, SAQC MEG 4055
White (3-11024, 5-30024) 1
8.712-361.0 Nozzle, SAQC MEG 0506
Red (4-20024 ) 1
8.712-362.0 Nozzle, SAQC MEG 1506
Yellow (4-20024) 1
8.712-363.0 Nozzle, SAQC, Meg 2506
Green (4-20024 ) 1
8.712-364.0 Nozzle, SAQC MEG 4006
White (4-20024 ) 1
