47Landa PGDC Operator’s Manual 8.916-596.0 - P
Landa Sure Fire Burner
REF PART NO. QTY DESCRIPTION NOTES
40 8.750-771.0 4 SCREW, 1/4-20 X 1/2", WHIZ LOC
41 9.802-745.0 1 SCREW, 10/32 X 1/2" SHCS
42 - 1 LABEL, BRAND NAME NOT SHOWN
43 9.801-268.0 1 LABEL, DISCONNECT POWER SUPPLY
44 - 1 LABEL, SERIAL PLATE
45 8.750-830.0 1 PLUG, HOLE 0.285 PLASTIC
46 9.807-339.0 1 LABEL, WIRING DIAGRAM, BURNER 115V-115V
- 9.807-340.0 1 LABEL, WIRING DIAGRAM, BURNER 230V-230V
- 9.807-341.0 1 LABEL, WIRING DIAGRAM, BURNER 230V-115V
- 9.807-342.0 1 LABEL, WIRING DIAGRAM, BURNER 115V-24V
- 9.807-343.0 1 LABEL, WIRING DIAGRAM, BURNER 230V-24V
- 9.807-344.0 1 LABEL, WIRING DIAGRAM, BURNER 12VDC
47 9.801-274.0 1 LABEL, BURNER LIGHTS
48 8.919-105.0 1 PLATE, TERMINAL BLOCK NUMBERS
49 8.716-451.0 1 TERMINAL, JUMPER SPADE
