Landmann 12202 - Single Part List; Fixing Elements

5
3.: Single part list
1. Lid Sheet II 1
2. Lid Sheet I 1
3. Left side panel 1
4. Right side panel 1
5. Hinge Pin 2
6. Top hinge 2
7. Handle bracket 2
8. Lid handle 1
9. Cooking Grill 1
10. Hot Plate 1
11. Cross Lighting tube 1
12. Burner 2
13. R Clip 2
14. Body ASSY 1
15. Left Bottom hinge 1
16. Right Bottom hinge 1
17. Gas Control Bar 1
18. Valve with ignitor 1
19. Valve 1
20. Control Panel 1
21. Control Knob 2
22. Drip pan 1
23. Drip pan handle 1
24. Screw M5x6 1
25. Hose 1
26. Regulator 1
27. Gas Hose connection 1
28. Hose Clamp 2
29. Bolt M6x12 9
30. Washer M6 5
31. Nut M6 5
32. Spring Washer M5 6
33. Flat Washer M6 6
34. Bolt M5x10 6
35. Screw M5x10 4
36. Nut M5
37. Warming Rack 2
38. Thermometer 1
39. Lava rocks 1 Bag
40. Lava rock grid 1
4.: Fixing elements
M5x15
4x
M5x8
1x
M5
4x
M5,2
4x 1x 3x 2x 2x
Note: All single parts in BOLD are pre - assembled.
